Material and specification processing

Plastic parts: PA66 UL 94V-0

Terminal: brass, 0.7 thick tin plating

Screws: copper, M3 nickel plated

performance

Rated voltage / current: 300V/20A

Service temperature: -40 ~ 105 C

Withstand voltage: AC2000V/Min

Insulation impedance: 500M ohm /DC500V

Applicable line diameter: 22-14AWG

Maximum locking torque: 0.5N.m 4.4Lb.in
