Material and electroplating

Soldering pin: brass, tin plated

Plastic parts: PA66, UL94V-0

Mechanical properties

Instantaneous temperature: 250, 5 seconds

Temperature range: -40 DEG to 120 DEG C

Wire length: 8-9mm

Electrical characteristics

Rated voltage: 300V

Rated current: 8A

Contact resistance: 20m ohm

Insulation resistance: 5000M ohm /1000V

Withstand voltage: AC1500V/1Min

Using line diameter: 22-16AWG 1.5mm2
