Material and electroplating

Screw: M2 copper galvanized

Contact material: phosphor bronze

Plastic parts: PA66 UL94V-0

Electrical performance

Rated voltage: 150V

Rated current: 8A

Contact resistance: 20m?

Insulation resistance: 5000M? \1000V

Withstand voltage: AC1500V\1Min

Using line diameter: 28-14AWG 1.5mm2

Mechanical properties

Temperature range: -40 ~ 105

Instantaneous temperature: 2505 seconds

Torque: 0.4Nm (3.61b.in)

Wire length: 7-8mm
