Material and electroplating

Contact material: phosphor bronze

Plastic parts: PA66 UL94V-0

Electrical performance

Rated voltage: 150V

Rated current: 5A

Contact resistance: 20m ohm

Insulation resistance: 5000M ohm \1000V

Withstand voltage: AC1500V\1Min

Using line diameter: 24 -20AWG 1nm2

Mechanical properties

Temperature range: -40 ~ 105

Instantaneous temperature: 250  5 seconds

Wire length: 11mn
